产品说明
摘要
Active Human Recombinant Alpha Synuclein Pre-formed Fibrils (Type 1)
产品应用
应用说明
Endogenous alpha-synuclein phosphorylation. 100 μM alpha synuclein protein monomer (GTX17668-pro) seeded with 10 nM alpha synuclein protein PFF (GTX17669-pro) in 25 μM Thioflavin T (PBS pH 7.4, 100 μl reaction volume) generated a fluorescence intensity of 13,000 Relative Fluorescence Units after incubation at 37ºC with shaking at 600 rpm. Fluorescence was measured by excitation at 450 nm and emission at 485 nm on a Molecular Devices Gemini XPS microplate reader.
*For best results, sonicate immediately prior to use.
产品属性
形式
Liquid
存储溶液
PBS
保存剂
No preservative
存放说明
Store as concentrated solution. Aliquot and store at -20ºC or below. Avoid freeze-thaw cycles.
浓度
Batch dependent (Please refer to the vial label for the specific concentration.)
Region/Sequence
Full-length without tagged; MDVFMKGLSK AKEGVVAAAE KTKQGVAEAA GKTKEGVLYV GSKTKEGVVH GVATVAEKTK EQVTNVGGAV VTGVTAVAQK TVEGAGSIAA ATGFVKKDQL GKNEEGAPQE GILEDMPVDP DNEAYEMPSE EGYQDYEPEA
表达系统
E. coli
纯化方式
Purified by ion-exchange chromatography
纯度
> 95% by SDS-PAGE
偶联
Unconjugated
注意事项
仅供实验室使用。不适用于人类或动物的任何临床，治疗或诊断用途。不适合动物或人类食用。
相关讯息
别名
synuclein alpha , synuclein alpha , NACP , PARK1 , PARK4 , PD1
数据库
研究领域
產品图片
|
GTX17669-pro Functional Assay Image
Primary rat hippocampal neurons show lewy body inclusion formation when treated with active Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro) at 4 μg/ml (D-F), but not when treated with control Alpha Synuclein Protein Preformed Fibrils (GTX17667-pro) at 4 μg/ml (A-C).
Tissue: Primary hippocampal neurons. Species: Sprague-Dawley rat. Fixation: 4% formaldehyde from PFA. Primary Antibody: Mouse anti-pSer129 Antibody at 1:1000 24 hours at 4ºC. Secondary Antibody: FITC Goat Anti-Mouse (green) at 1:700 for 1 hours at RT. Counterstain: Hoechst (blue) nuclear stain at 1:4000 for 1 hour at RT. Localization: Lewy body inclusions. Magnification: 20x.
|
|
|
GTX17669-pro Functional Assay Image
Immunohistochemistry analysis of rat brain injected with active human alpha synuclein PFFs (GTX17669-pro). Species: Female Sprague-Dawley Rat. Rat was injected with 2μL active human alpha synuclein PFFs (GTX17669-pro) in each of 2 injection sites: AP+1.6, ML+2.4, DV-4.2 from skull; and AP-1.4, ML+0.2, DV-2.8 from skull. 30-days post-injection. Fixation: Saline perfusion followed by 4% PFA fixation for 48 hrs. Secondary Antibody: Biotin-SP Donkey Anti-Rabbit IgG (H+L) at 1:500 for 2 hours in cold room with shaking. ABC signal amplification, DAB staining. Magnification: 20X. Alpha synuclein pathology is seen in the striatum close to an injection site.
|
|
|
GTX17669-pro Image
Active alpha synuclein preformed fibrils (GTX17669-pro) seed the formation of new alpha synuclein fibrils from the pool of alpha synuclein monomers (GTX17668-pro). Thioflavin T is a fluorescent dye that binds to beta sheet-rich structures, such as those in alpha synuclein fibrils. Upon binding, the emission spectrum of the dye experiences a red-shift, and increased fluorescence intensity. Thioflavin T emission curves show increased fluorescence (correlated to alpha synuclein protein aggregation) over time when 10 nM of active alpha synuclein preformed fibrils (GTX17669-pro) is combined with 100 μM of alpha synuclein monomer (GTX17668-pro), as compared to active alpha synuclein preformed fibrils (GTX17669-pro) alone and alpha synuclein monomer (GTX17668-pro) alone. Thioflavin T ex = 450 nm, em = 485 nm.
|
|
|
GTX17669-pro Image
SDS-PAGE of ~14 kDa active Human Recombinant Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro). Lane 1: Molecular Weight Ladder (MW). Lane 2: active Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro).
|
|
|
GTX17669-pro Functional Assay Image
Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro) was shown to be taken up by SH-SY5Y cells and transmitted to neuronal iPSCs within 14 days.
Blue : Hoechst
Green : SH-SY5Y-GFP
Red : Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro)
Purple : Tubulin
|
|
|
GTX17669-pro Functional Assay Image
Toxicity results comparing active Human alpha Synuclein protein (Pre-Formed Fibrils) (GTX17667-pro) and active Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro). Data was graphed after live cell imaging results were obtained using the following procedure: After 8 days in vitro, primary rat mixed cortical neuron cells were treated with 500 μg/ml of Type 1 and Type 2 Alpha Synuclein Proteins for 20 hours at 37˚C.
|
|
|
GTX17669-pro Image
Transmission electron microscopy (TEM) image of GTX17669-pro Human alpha Synuclein protein (active, Pre-Formed Fibrils).
|
|
|
GTX17669-pro Image
Transmission electron microscopy (TEM) image of GTX17669-pro Human alpha Synuclein protein (active, Pre-Formed Fibrils).
|
|
|
GTX17669-pro Functional Assay Image
ICC/IF analysis of human iPSC-derived neurons treated with Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro).
Figure A : Negative control; no fibrils added to well.
Figure B : 7 days after addition of active recombinant human pre-formed fibrils (Type 1). Fibrils were sonicated before use and applied 2.5 ug per well
Green : Primary Antibody : Mouse Anti-Alpha Synuclein (phospho Ser129) Monoclonal Antibody at 1:1000
Blue : Hoechst
Magenta : beta Actin
|
|
|
GTX17669-pro Functional Assay Image
Confocal imaging shows NeuN+ (mature) primary cortical neurons filled with Fluorescently-labelled Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro). GTX17669-pro seed endogenous alpha synculein phosphorylation after 7 days.
|
|
|
GTX17669-pro Functional Assay Image
Fluorescently-labelled Alpha Synuclein Protein Preformed Fibrils (GTX17669-pro) were taken up, transported into the soma, and induced alpha synuclein aggregation in mouse neurocortical primary cells.
Left : Neurites filled with fluorescently-labelled alpha synuclein seeds in a microfluidic co-culture system after 24 hours.
Right : Alpha synuclein seeds within the soma and neurites of mouse neurocortical primary cells after 24 hours.
|
